■ Material: SUS304
*The price is for 30 m. However, for each of the sizes 22A and 25A, the list price is the price of a 25 m chain. *Other lengths are also available. *Note: Do not use as a suspension chain. *Articles marked with ( * ) in the dimension table below are in stock. All others are on back order.
Request Quotation for This Item
SHARE
Drawing / Dimension / Request for quotation
To request a quotation, check the RFQ column for any product(s) you would like a quotation for.
The product(s) you select will be added to the quotation request list.
| RFQ | Drawing | No. | List Price | Size | d(mm) | L(mm) | B(mm) | Weight/m(g) | Ref. Work Load Limit(kg) | Stock |
|---|---|---|---|---|---|---|---|---|---|---|
|
AK7039 | $255.60 | 2A | 2 | 16 | 7.5 | 68 | 30 | * | |
|
|
AK7040 | $310.70 | 3B | 3 | 30 | 11 | 146 | 65 | * | |
|
|
AK7041 | $533.90 | 3A | 3 | 25 | 11 | 153 | 65 | ||
|
|
AK7042 | $424.70 | 4B | 4 | 34 | 14 | 266 | 120 | * | |
|
|
AK7043 | $661.90 | 4A | 4 | 28 | 14 | 282 | 120 | ||
|
|
AK7044 | $783.10 | 5B | 5 | 38 | 18 | 429 | 180 | * | |
|
|
AK7045 | $841.90 | 5A | 5 | 30 | 17 | 493 | 180 | ||
|
|
AK7048 | $1,064.90 | 6B | 6 | 43 | 21 | 633 | 270 | * | |
|
|
AK7049 | $1,122.30 | 6A | 6 | 36 | 21 | 694 | 270 | ||
|
|
AK7050 | $1,459.00 | 7B | 7 | 51 | 24 | 820 | 360 | * | |
|
|
AK7104 | $1,598.20 | 7C | 7 | 51 | 24.5 | 907 | 360 | ||
|
|
AK7052 | $1,947.50 | 8B | 8 | 54 | 27 | 1150 | 480 | * | |
|
|
AK7053 | $2,208.00 | 8A | 8 | 48 | 28 | 1240 | 480 | ||
|
|
AK7105 | $2,139.00 | 8C | 8 | 54 | 28 | 1220 | 480 | ||
|
|
AK7054 | $2,444.00 | 9B | 9 | 57 | 31 | 1520 | 600 | * | |
|
|
AK7055 | $2,557.50 | 9A | 9 | 54 | 32 | 1550 | 600 | ||
|
|
AK7115 | $3,320.00 | 10B | 10 | 60 | 35 | 2000 | 750 | ||
|
|
AK7056 | $3,020.00 | 11A | 11 | 66 | 39 | 2400 | 900 | ||
|
|
AK7057 | $4,260.00 | 13A | 13 | 78 | 46 | 3400 | 1250 | ||
|
|
AK7058 | $6,345.00 | 16A | 16 | 96 | 56 | 5100 | 1900 | ||
|
|
AK7059 | $8,960.00 | 19A | 19 | 114 | 66 | 7200 | 3750 | ||
|
|
AK17080 | $10,570.00 | 22A | 22 | 132 | 77 | 9600 | 5000 | ||
|
|
AK17081 | $13,675.00 | 25A | 25 | 150 | 87 | 12500 | 7250 |
